Description
ABB 3BHE023584R2634 PPD113B03-26-100110 Ethernet switchAB is used for data communication between 100Base-TX twisted pair and 100Base-FX optical cable. It is most suitable for intelligent cell or optical fiber to desktop connector, and automatically ADAPTS to the transmission rate of 10Mbps and 100Mbps, which is convenient for users to upgrade. It extends the limit of network transmission distance from 100M of twisted pair to more than 100KM, and can easily realize the interconnection between motherboard servers, Repeaters, hubs, terminals and terminals.
● Using high-quality photoelectric integrated modules to provide good optical and electrical characteristics,
● Ensure reliable data transmission and long working life
● Support full duplex or half duplex mode, and with automatic negotiation capability
●10Mbps and 100Mbps automatically adapt
● Network port supports automatic cross identification, no manual switch operation
● In-band storage and forwarding mechanism, cache 1MB, support a variety of protocols
● In line with carrier-grade operating standards, the average trouble-free operation of more than 50,000 hours
● Power supply: DC12 ~ 48V can be reversed
● SC fiber interface (ST, FC interface optional)
specification
Standard:
IEEE 802.310BaseT
IEEE 802.3u 100BaseT(X) and 100Base FX
Interface:
Optical fiber port: One 100BaseFX port (SC, ST, FC port optional)
RJ45 ports: 2 10/100BaseT (X) automatic detection, full/half duplex MDI/MDI-X adaptive
LED indicator: PWR power lamp, FDX optical fiber indicator,ACT network data transmission indicator, LINK network connection indicator
Optical fiber technical parameters
① Transmission fiber
Multimode: 50/125, 62.5/125
Single mode: 8.3/125, 8.7/125, 9/125, 10/125μm
② Transmission distance
Multi-mode: 2km
Single mode: 20km, according to user requirements can be customized 40Km, 60Km, 80km, 120km.
Connection cable UTP5 cable: 100m
