Description
The AC10272001R0101 5SXE10-0181 5SHY35L4520 is a high-performance module designed for high voltage direct current (HVDC) applications. Manufactured by ABB in Switzerland, it offers excellent efficiency, high power density, reliability and long service life.
specification
– Rated voltage: 6500 V
– Rated current: 1000 A
– Switching loss: 5.0J
– Conduction loss: 2.5V
– Switching frequency: 2 kHz
– Junction temperature 175°C
– Weight: 15 kg
– Dimension Length: 300 mm, width: 250 mm, height: 150 mm
Mounting hole distance: 250 mm
Main functions and features
High performance and reliability
The module adopts advanced digital signal processing technology, has high-speed operation and response ability, and can realize fast fault detection and protection action.
High reliability and stability ensure normal operation in harsh power systems or industrial environments.
Multiple protection functions
Rapid detection and protection of current, voltage, frequency, phase sequence, short circuit, overvoltage and other anomalies.
Supports fault recording and event logging, facilitating fault analysis and system optimization.
Communication and integration capabilities
Supports a variety of communication interfaces and protocols (such as IEC 61850, Modbus, etc.), and can communicate and integrate with other devices to achieve system monitoring and data exchange.
Flexible scalability and configuration options to meet different application requirements.
Programmable logic features
Users can perform logic programming and parameter setting according to actual needs to achieve personalized protection and control functions.
High power density and high voltage capability
Suitable for high-power applications, providing high power density and efficient energy conversion.
Supports high voltage circuits, commonly used in power electronics and high voltage inverters.
Low loss and high frequency characteristics
Low conduction and shutdown losses help improve system efficiency and reduce energy consumption.
Higher switching frequency for high frequency applications.
Simplified drive and protection functions
The integrated drive circuit simplifies the design and control of the external drive circuit.
Equipped with overcurrent, overheat, overvoltage and other protection functions to ensure the safe operation of equipment and systems.
Apply
– Simulation
– Instrumentation
– Industrial Control
– Process control and monitoring
– Factory Automation
– Intelligent networking PLC controller
– Automatic test
– Data acquisition
