GE DS200DCFBG1B feedback module

Description

DS200DCFBG1B is a DC feedback module produced by General Electric (GE), mainly used in industrial power supply applications.



This module has the following characteristics:



The rated output voltage is 24V DC, and the output voltage can be adjusted by rotating the potentiometer “Output Adjust” on the front.

The rated output current is 5A and the rated output power is 120W.

The power range is 115/230 V AC (90-132 V AC, 180-264 V AC, 210-375 V DC), with a typical efficiency of 86% automatically selected.

Adopting low power consumption and low heat natural convection cooling method, the ambient temperature range during operation is 35…+70 ° C.

Equipped with open circuit, overload, and short circuit stable integrated input fuse redundancy unit CPA RU, providing true redundancy, it can be used as an accessory to provide signal contacts with normal output voltage “13-14” (relay) status indicator LED main switch mode power supply, providing two voltage input ranges.

Equipped with two large capacity capacitors, ensuring a power buffer of at least 30 milliseconds (230 volts AC).

By using the potentiometer “OUTPUT Adjust”, the output voltage can be adjusted within a certain range of 22.5 to 28.5 V DC.
