Description
GE DS200FCGDH1B is a Gate Control Distribution and Status Card (FCGD) developed by General Electric for its Mark V board series. It can be installed in many GE branded drives and serves as an interface system for six pulse, phase controlled irreversible bridges. DS200FCGDH1B has the following characteristics:
Installed on DIN rails, with dimensions of 9.2×6.3 inches and a weight of 0.45 kilograms.
The working temperature range is -30 to 65 ° C.
The power supply voltage is 24 V DC.
It has 12 channels.
The range is -8 mV to+45 mV.
It can receive multiplexed unit status signals from each bridge leg and decode and deallocate the unit gate signals for each bridge leg.
It can receive bridge feedback signals, scale them, and then transmit voltage, frequency, and current status data back to the DSPC board.
Through the VME backplane, it receives SCR ignition data from the DS200DSPC (DSPC, VME processor) chip and transmits feedback and diagnostic data.
The integrated IMOK LED status indicator provides users with basic system status.
In summary, GE DS200FCGDH1B is a powerful gated power distribution and status card suitable for various application scenarios that require precise control and monitoring.
