GE DS200ITXDG1ABA Dynamic brake buffer plate

Description

GE DS200ITXDG1ABA is an industrial control spare manufactured by General Electric (GE) and is part of the Mark V series, specifically the dynamic brake buffer plate. This board is designed to limit voltage transients on IGBTs (Insulated Gate Bipolar Transistors) and all known operating conditions of the driver.
The DS200ITXDG1ABA board has the following characteristics:
Dynamic braking function: As a dynamic braking buffer plate, its main function is to limit voltage transients on the IGBT and protect the circuit from voltage shocks.
Adjust Output: The board can also adjust the output of the IGBT gate driver board to match the electrical characteristics of the AT frame driver. The AT framework driver has both variable and constant torque applications, with a rated output current of 500ARMS for variable torque applications.
Multiple connector types: The DS200ITXDG1ABA board is equipped with three different types of connectors, including bus I/O connectors, input connectors for DBPL, and stab connectors. These connectors are used for connecting and communicating with other devices or circuits.
Industrial grade applications: Due to its crucial role in industrial control systems, DS200ITXDG1ABA boards are commonly used in environments that require high reliability and stability, such as power, energy, and automation control.
