GE IS200TBTCH1C Terminal board

Description

IS200TBTCH1C Technical Specification

Compatibility PTCC I/O package

Inputs for Simplex Pack Twelve

User Manual GEH-6721G Mark VIe Control System Guide Volume 2

Manufacturer General Electric Company, General Electric Industrial Systems

Model thermocouple input

Number of DC type connectors 2

Part number IS200TBTCH1C

Series Mark VIe

System Application Type Simplex



Product Description



The thermocouple input (TBTC) terminal board IS200TBTCH1C is part of the Mark VIe series produced by General Electric Company. This board will accept 24 main thermocouple inputs for T, S, K, J, and E. If this board is used with the PTCH2 board in a simplex system, it can accept three additional thermocouple inputs, labeled R, B, and N. There are two TBTC models, which are IS200TBTCH1C, indicating that it has two DC type connectors and is only used for simplex applications. This board will use two PTCC components, thus allowing 24 inputs.



When connecting the IS200TBTCH1C board as part of the Mark VIe series, the I/O package used will be directly calibrated into the TBTC J-type connector, and the required cables will also depend on the redundancy level required by the board. One characteristic of this board is that the thermocouple input on the board can be ungrounded or grounded. The input distance from the turbine control panel can reach 984 feet. The I/O processor connected to this device will perform analog-to-digital linearization and conversion on a single thermocouple input.



The thermocouple input of the IS200TBTCH1C board can support a wide input range from negative 8 volts to up to positive 45 volts. The board has cold contacts and its operating temperature may range from minus 22 degrees Fahrenheit to 149 degrees Fahrenheit. Cold contacts or CJ signals can be monitored by entering the signal space.
