GE IS230PCAAH1B Core Analog Module

Description

The IS230PCAAH1B, a Core Analog Module specifically designed for the Mark VIe system, was created by General Electric This module, along with the Core Analog (TCAS and TCAT) terminal board, plays a pivotal role in delivering a substantial amount of the necessary analysis signal I/O for the effective operation of a gas turbine The IS230PCAAH1B module, in connection with TCAT, provides a wide range of functionalities, including thermocouple inputs, 4-20 mA current loop I/O, seismic inputs, Linear Variable Differential Transformer (LVDT) excitation and inputs, pulse rate inputs, and servo coil outputs The integration of the IS230PCAAH1B module and TCAT significantly contributions to the comprehensive analysis signal handling within the gas turbine system
ControlST Version required for IS220PCAAH1B
Install BPPC I/O Upgrade V05.01.03 across the system if currently having ControlST V04.04
Prior to ControlST V04.04 upgrade to ControlST V04.07.08C or Control ST V05.0204C, or the highest available version at the next scheduled output, then install BPPC I/O Upgrade V05.01.03 across the system
Reliability
IS230PCAAH1B board is very reliable and so less prone to damage But the improved handling and poor storage can affect the functionality of the card So that we recommend keeping the cards in static sensitive storage boxes in recommended conditions
