HIMA X-SB01 digital input module

Description

HIMA X-SB01 is a digital input module used in the Programmable Electronic Equipment System (PES) HIMax. It can evaluate up to 16 digital input signals, with digital inputs being currents, according to IEC 61131-2 (based on type 1). This module has been certified for T [gf] dc [/gf] V safety related applications and meets SIL 3 (IEC 61508, IEC 61511, and IEC 62061), category 4 (EN 954-1), and PL e (EN ISO 13849-1).

The HIMA X-SB01 module can be inserted into any backplane slot, except for slots reserved for system bus modules. For more information, refer to the system manual (HI 801 001 E). This module is used to evaluate up to 16 digital input signals. The digital input is current according to IEC 61131-2 (based on type 1). This module has passed the T [gf] dc [/gf] V security related application certification, reaching SIL 3 (IEC 61508, IEC 61511, and IEC 62061), category. 4 (EN 954-1) and PL e (EN ISO 13849-1). For more information on standards, please refer to the HIMax Safety Manual (HI 801 003 E) for testing and certification of modules and HIMax systems.
