IS200EGPAG1BEC Gate pulse amplifier board

Description

IS200EGPAG1BEC is a gate pulse amplifier board located in the power conversion cabinet and can be connected to the power conversion module. This board is one of the boards under the bridge and protection board/module, and although it can operate independently, it usually requires power to be obtained from one of the EPDM modules.
The IS200EGPAG1BEC board receives feedback from two thermal switches installed on the SCR heat sink. These switches are triggered and opened at the alarm level and trip level, and are directly connected to IS200EGPAG1BEC. Before being triggered, the switch must reach a trip level of 190 degrees Fahrenheit and an alarm level of 170 degrees Fahrenheit. These switches can be turned on individually or together. If only one switch is open, an over temperature alarm related to the bridge will occur; If both switches are open, it will indicate that a trip and fault have occurred.
In addition, the IS200EGPAG1BEC board also has five jumpers, which allow users to choose the specific application configuration they need and easily adjust the jumper configuration before installation.
