NI PXIE-6556 High speed digital I/O module

Description

NI PXIe-6556 is a high-speed digital I/O module launched by NI Corporation, with 24 channels that can be used for validation or production testing. This module has a four quadrant unit pin parameter measurement unit (PPMU) function, which can drive and measure current and voltage. The PPMU settings for each channel can be individually programmed and have a voltage level range of -2 V to 7 V or -1 V to 7 V. In addition, the module also has functions such as real-time hardware comparison, data latency, scripting, and onboard high-resolution clock.

PXIe-6556 can be integrated with other devices, including power supplies, digitizers, and switches, to achieve a multifunctional, high-performance mixed signal testing system. In addition, it can also be used in conjunction with NI-HSDIO driver software, providing an intuitive and flexible API, with multiple advanced functions such as hardware timing excitation and response, timing and analog calibration at various temperatures, and board power consumption measurement. With this module, users can easily and quickly create, edit, and import digital waveforms.

In summary, NI PXIe-6556 is a powerful, flexible, and adjustable high-speed digital I/O module suitable for various semiconductor device testing applications.
